MAXX Digital - ThunderRAID3 8 Bay



DESCRIPTION:



SAME GREAT DESIGN AS THE ORIGINAL THUNDERRAID, BUT WITH THE BLISTERING SPEEDS OF THUNDERBOLT 3.



Maxx Digital introduces one of the first 8 Bay Thunderbolt 3 chassis to allow up to 80TB of raided storage on a Thunderbolt 3 connection. With Thunderbolt 3 you will see read and write speeds of 1200+ MB/sec on a newer Apple iMac, or MacBook Pro with Thunderbolt 3. This chassis is very compact so it does not take up a lot of space at home or in the office.

This innovative high-speed technology was designed for speed, simplicity and flexibility. Thunderbolt 3 uses a dual protocol which lets you connect your devices with a single cable and transfer data up to 40Gbps in both directions. This gives you more than enough bandwidth to daisy chain 7 Thunderbolt™ devices.



FEATURES:


  • RAID level 0, 1, 1E, 3, 5, 6, 10, 30, 50, 60, Single Disk or JBOD
  • Multiple RAID selection
  • Support up to 1MB stripe size
  • Online array roaming
  • Online RAID level/stripe size migration
  • Support global hot spare and local hot spare
  • Instant availability and background initialization
  • Advanced configuration for smooth data streaming
  • Disk scrubbing/ array verify scheduling support
  • Multiple pairs SSD/HDD disk clone function
  • SSD automatic monitor clone (AMC) support
  • Complete configuration management suite:
    • McRAID manager: browser-based management tool (LAN or Thunderbolt)
    • Push Buttons and LCD Display panel for setup and status
    • Command Line Interface (CLI) - scriptable configuration tool
    • API libraries support - combine GUI with user management utility
    • SNMP support for remote monitoring
    • SMTP support for email notification


SPECIFICATIONS:



Controller Architecture:

  • 800 MHz Dual core ROC for RAID core and SAS microcode
  • 1GB on-board DDR3-1333 SDRAM with ECC protection
  • Support up to 8 x 6Gb/s SAS/SATA 3.5"/2.5" HDDs/SSDs
  • Support bootable from RAID storage volume
  • Controller level hardware encryption support
  • Redundant flash image for adapter availability
  • System status indication through LCD, LED and alarm buzzer
  • Intelligent power On/Off function
  • Battery Backup Module ready (optional)



INCLUDED:


  • (1) ThunderRAID 3
$4,875.00
