Z CAM - E2-F6 Full Frame Cinema Camera

Previous Product | Next Product



DESCRIPTION:



Professional 6K Super 35 Cinematic Camera


Z Cam's E2-S6 is a small but powerful camera at an amazing value. Silent, Capable, Sturdy, and designed to be your perfect companion camera or run-and-gun rig. Ideal for your B-roll or for shots that require a lightweight, compact form-factor camera sitting in a tight space.





FEATURES:


  • 6K @75fps* & 4K @100fps max
  • 10-bit color
  • Super 35mm CMOS sensor
  • 14 stops dynamic range
  • ZRAW supported
  • EF / PL lens mount
  • Gigabit Ethernet for data, control & live streaming with Z CAM E2 sync cable (not included)


SPECIFICATIONS:



Sensor

  • Type: Super 35mm CMOS Sensor
  • Size: 37.09 x 24.75 mm
  • Effective Pixels: 26 Megapixels
  • 14 stops of Dynamic Range



Camera

  • Lens Mount:  EF / PL (different hardware variants)
  • On-Board Mic:  Stereo
  • Recording Media:  1 CFAST  2.0 slot



Resolution & Max Frame Rate

  • 6244x4168 @30fps max (6K Open Gate)
    6144x3240 @48fps max (DCI 6K)
    6144x2592 @60fps max (DCI 6K 2.4:1)
    5760x3240 @48fps max (6K UHD)
    5552x4164 @30fps max (5K 4:3)
    4992x4160 @30fps max (5K 6:5)
    4096x2160 @72fps max (DCI 4K) *
    4096x1728 @120fps max (DCI 4K 2.4:1)
    3840x2160 @72fps max (4K UHD) *
    3840x1620 @90fps max (4K UHD 2.4:1)
    1920x1080 @120fps max (FHD)

    * Cropping / Supersampling selectable



    I/O Connectivity

    • Video Connectors
      • HDMI 2.0 Type A (video output up to DCI 4K @60fps, 10-bit 4:2:2)



    • Audio Connectors
      • 3.5 mm stereo jack socket for active microphone only, or 5-pin LEMO port for dual channel XLR microphone (requires additional XLR audio connector)
      • 3.5 mm stereo jack socket output



    • Other
      • 1 x USB Type-C
      • 2 x Serial Port
      • 2.5 mm jack socket (Sony LANC compatible)



    • Wireless
      • 5G, 802.11n with external antenna port



    Power

    • Battery Type
      • Sony NP-F series compatible (Battery not included)
      • Power Output: DC 12V (2-pin LEMO socket)



    • Connectors
      • DC 12V (2-pin LEMO socket), with LEMO connector



    Temperatures

    • Operating
      • 32 to 104°F / 0 to 40°C



    • Storage
      • -4 to 140°F / -20 to 60°C



    Physical

    • Mounts
      • 1/4"-20 Tripod mount
      • 8x 1/4"-20 Accessory mounts



    • Construction
      • Aluminum



    • Dimensions
      • 91.2 mm x 99.2 mm x 99.1 mm (without lens)



    • Weight
      • TBD



    Package Weight

    • TBD






      INCLUDED:


      • Z CAM™ E2-F6 Full-Frame Camera Unit
      • AC/DC Power Adapter
      • Power Cables (US / EU / UK)
      • Quick User Guide
      • Warranty Card
      $3,999.00
